Descrizione

CARATTERISTICHE HARDWARE
Dimensions: 120.8 × 78.5 × 20.9 mm
Tipo di antenna: 2x High-Gain Dual Band Antennas
Chipset: Realtek Wi-Fi 6 Chipset

CARATTERISTICHE WIRELESS
Standard wireless:
– IEEE 802.11ax/ac/n/a 5 GHz
– IEEE 802.11ax/n/g/b 2.4 GHz
– Bluetooth 5.2
WLAN Signal Rate (5 GHz):
– 11ax: Up to 1201 Mbps(dynamic)
– 11ac: Up to 867 Mbps(dynamic)
– 11n: Up to 300 Mbps(dynamic)
– 11a: Up to 54 Mbps(dynamic)
WLAN Signal Rate (2.4 GHz):
– 11ax: Up to 574 Mbps(dynamic)
– 11n: Up to 300 Mbps(dynamic)
– 11g: Up to 54 Mbps(dynamic)
– 11b: Up to 11 Mbps(dynamic)
WLAN Reception Sensitivity (5 GHz):
– 11ax HE80: -57.0dBm
– 11ax HE40: -60.0dBm
– 11ax HE20: -63.0dBm
– 11ac VHT80: -59.5dBm
– 11ac VHT40: -62.5dBm
– 11ac VHT20: -67.5dBm
– 11n HT40: -69.5dBm
– 11n HT20: -72.5dBm
– 11a 54Mbps: -74.0dBm
– 11a 6Mbps: -94.5dBm
WLAN Reception Sensitivity (2.4GHz):
– 11ax HE40: -60.0dBm
– 11ax HE20: -63.0dBm
– 11n HT40: -69.5dBm
– 11n HT20: -72.5dBm
– 11g 54Mbps: -74.0dBm
– 11b 11Mbps: -88.0dBm
WLAN Transmit Power:
– 5 GHz : 27dBm(FCC) / 23dBm(CE) (EIRP)
– 2.4 GHz : 25dBm(FCC) / 20dBm(CE) (EIRP)
WLAN Modes: Infrastructure mode
Sicurezza wireless: Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x
Modulazione: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM

ALTRO
Certificazione: CE, FCC, RoHS
Contenuto della confezione:
– Archer TX20E
– Two High-Gain Dual Band Antennas
– Low-Profile Bracket
– Bluetooth Header Cable
– Quick Installation Guide
– Resource CD
Requisiti di sistema: Windows 11/10(64-bit) only
Ambiente:
– Operating Temperature: 0?~40? (32?~104?)
– Storage Temperature: -40?~70? (-40?~158?)
– Operating Humidity: 10%~90% non-condensing
– Storage Humidity: 5%~90% non-condensing
